ZBTK single-pendulum rust removal machine
DP-CL2000-SC-W-KP
First. Configuration and parameters
|
Serial Number |
Name |
Brand | Quantity |
|
1 |
Cabinet |
Dp laser | 1 set |
|
2 |
Laser source |
Raycus 2000W | 1 set |
|
3 |
Welding Head |
Dp laser | 1 set |
|
4 |
Control system |
Dp laser | 1 set |
|
5 |
Wire feeder |
Han Li sch1500 | 1 set |
Second. Technical Parameters
|
Serial Number |
Model |
Describe | Remarks |
|
1 |
The central wavelength |
1060nm-1080nm | |
|
2 |
Laser power |
1500w | |
|
3 |
Fiber length |
10m | Outside 8 meters |
|
4 |
The weight of the welding head |
0.7kg | |
|
5 |
cooling method |
Water cooling | |
| 6 | Operating environment | 10-35°c, Relative humidity 30%<=RH<=85%, NO Condensation | |
| 7 | Electric power requirement | 220V±5%, 50Hz | |
| 8 | The overall power | 5Kw | |
| 9 | External size of the whole machine | 950*520*800 | Portable small cabinet |
| 10 | Weight | 150kg | Portable small cabinet |
| 11 | Security classification | Class IV | |
| 12 | Total power supply protection level | IP54 |
