Hand-held fiber laser welding machine
DPH-2000-SCBD-W-RC
First. Configuration and parameters
|
Serial Number |
Name |
Brand | Quantity |
|
1 |
Cabinet |
Dp laser | 1 set |
|
2 |
Laser source |
Dp laser | 1 set |
|
3 |
Welding Head |
Dp laser | 1 set |
|
4 |
Control system |
Dp laser | 1 set |
|
5 |
Wire feeder |
Dp laser | 1 set |
Second. Technical Parameters
|
Serial Number |
Model |
Describe | Remarks |
|
1 |
The central wavelength |
1060nm-1080nm | |
|
2 |
Laser power |
1500w | |
|
3 |
Fiber length |
10m | Outside 8 meters |
|
4 |
The weight of the welding head |
0.7kg | |
|
5 |
cooling method |
Water cooling | |
| 6 | Operating environment | 10-35°c, Relative humidity 30%<=RH<=85%, NO Condensation | |
| 7 | Electric power requirement | 220V±5%, 50Hz | |
| 8 | The overall power | 5Kw | |
| 9 | External size of the whole machine | 790*376*623 | Air-cooled all-in-one machine |
| 10 | Weight | 67Kg | |
| 11 | Security classification | Class IV | |
| 12 | Total power supply protection level | IP54 |
