CNC Turret type automatic lathe parameters















Machine data/model







Unit



FDL-46DW

 		FDL-52DW FDL-66DW FDL-75DW FDL-75100DW FDL-52H FDL-75/85H

                               | Bed rotation diameter

                               |  Disc type processing diameter

processing capacity| Long axis processing rotation diameter

                                | Maximum processing length

                                | |Distance between two tipes

mm

mm

mm

mm

mm

460

400

210

350

370

560

450

300

500/750/1000

550/800/1100

560

450

300

500/750/1000

550/800/1100

560

450

300

460/750/1000

520/800/1100

 580/650

580/630

360/400

1000/1500/2000/3000

1100/1600/2100/3100

460

400

260

400

420

920

600

440(600)

750/1000/1500/2000

800/1100/1600/2100

X/Z troke| X-axis travel

               | Z-axis travel

mm

mm

210

400

225

610/810/1100

225

550/800/1100

225

550/800/1100

350

1120/1620/2120/3120

245

500

330

940/1240/1840/2440

Spindel       | Spindel nose form

parameters | Chuck/ collet

                   | Spindel through hole diameter

                   | Bar stock passing diameter

                   | Spindel speed range

-

inch

mm

mm

rpm

A2-5

6

56

46

5000

A2-6

8

66

52

4200

A2-6

8

79

66

4200

A2-8

10

88

75

3500

A2-8/A2-11

10/12

88/105

75/91

2500

 A2-6

8

66

52

3000

A2-8/A2-11

10/12

88/105

75/91

2500

Moving speed| X/Z axis rapid moving speed

m/min

 30/30 30/30 30/30 30/30  18/18  18/18   18/18





Position | Minimum setting unit(x/z)

                | X/Z axis repeated position accuracy

                | X/Z axis position accuracy

mm

mm

mm

0.001

0.003

0.002

0.001

0.003

0.002

0.001

0.003

0.002

0.001

0.003

0.002

0.001

0.003

0.002

 0.001

0.003

0.002

 0.001

0.003

0.002

              | Position turret

  Turret   | Cylindrical/transverse tool apron

              | Boring hole tool arpon

              | Turret center heught

T

mm

mm

mm

12

25

32

80

12

25

40

100

12

25

40

100

12

25

40

100

12

25

40

100

12

25

32

80

12

25

40

100

                       | Spindel motor

                       | X-axis motor

Motor power   | Z-axis motor

                       | Tool changing motor

                       | Hydraulic motor

                       | Water pump motor

kw

kw

kw

kw

kw

kw

7.5/11

1.2

1.2

0.75

1.5

0.45

11/15

1.8

1.8

0.75

1.5

0.45

11/15

1.8

1.8

0.75

1.5

0.45

 15/18.5

3.0

3.0

0.75

1.5

0.45

 18.5/22

3.0

3.0

0.75

1.5

0.45

 11/15

1.8

1.8

0.75

1.5

0.45

 22/30

3.0

3.0

0.75

2.0

0.45

              | Tailstock sleeve diameter

              | Tailstock sleeve travel

Tailstock | Maximum travel of tailstock

              | Tailstock form

              | tailstock sleeve taper

mm

mm

mm

-

MT

65

80/120

300

Hydraulic

MT4

80

80/150

450/750/950

Hydrulic

MT5

80

80/150

450/750/950

Hydraulic

MT5

 80

80/150

450/750/950

Hydraulic

MT5

 100

120

1250

Hydraulic

MT5

 75

80

300

Hydraulic

Style4

 100

80630/930/1530/2130

Hydraulic

style 5

               | Fuel tank

Capacity | Water tank

L

L

60

100

60

100

60

100

60

100

80

200

 60

100

80

200

  Machine size | Machine weight

                        | Length*width*height

kg

m

3850

2.5x1.8x1.95

4850/5250/5800

2.85(3.15)/3.75x1.9x2.05

4850/5250/5800

2.85(3.15)/3.75x1.9x2.05

4950/5350/5950

2.85(3.15)/3.75x1.9x2.05

6850/7300/7800/8500

4.4x2.25x2.45

 4200

2.5x1.7x1.85

 5500/6900/7500/7900

3.5/4.2/4.9/5.8x2x2.2
